Alpha Trading International is a global distributor of Genuine OEM parts from Danfoss and Eaton Airflex.
Danfoss Airflex VC units are built for severe clutching or braking applications in which large inertia loads and sustained slippage would normally result
in loss of torque and reduced operating life.
Torque: up to 1,706,629 Nm
Max. speed: 1,800 rpm
Typical applications: grinding mills.
 The Danfoss couplings feature electronic slip detection and automatic resets to maintain driveline control and protection.
Eaton Airflex, the original maker of the Fawick Clutch, is a trusted leader in industrial clutches and brakes. Renowned for durability and precision, Eaton Airflex products perform reliably in heavy-duty applications.
Danfoss industrial clutches and brakes deliver superior performance and long life. Their torque-limiting couplings are engineered to handle torque spikes from variable-frequency drives used in mills and other demanding systems.
Airflex VC Series Heavy-Duty Drum Clutches & Brakes
The Airflex VC Series is specifically engineered for severe, high-torque clutching and braking applications where massive inertia loads and sustained slippage are common. Featuring an innovative open-top, ventilated design, VC series clutches rapidly dissipate heat during high-slip startup cycles, protecting your machinery from thermal breakdown and ensuring exceptional service life under the harshest operating conditions.
Product Specifications & Model Breakdown
| Model | Drum Diameter | Friction Width | Torque Rating (at 75 PSI) | Target Applications & Equipment |
|---|---|---|---|---|
| 38VC1200 | 38" | 12" | 680,000 lb-in (76,800 Nm) | Mid-to-large size grinding mills, severe-duty drawworks, and industrial winches. |
| 46VC1200 | 46" | 12" | 950,000 lb-in (107,000 Nm) | Heavy metal-forming presses, stamping equipment, and marine propulsion systems. |
| 52VC1200 | 52" | 12" | 1,215,000 lb-in (137,000 Nm) | Primary rock crushers, high-inertia shredders, and large-scale marine drives. |
| 51VC1600 | 51" | 16" | 1,610,000 lb-in (182,000 Nm) | High-thermal demand oilfield machinery, heavy draglines, and continuous slip drives. |
| 66VC1600 | 66" | 16" | 2,800,000 lb-in (316,000 Nm) | Ultra-high capacity ball mills, SAG mills, and heavy-duty industrial power transmissions. |
Engineering Features & Performance Benefits
- Maximum Thermal Dissipation: Built with ventilated friction shoes that allow continuous airflow directly through the assembly. This open-top design eliminates heat build-up, preventing premature lining wear and structural distortion.
- Rigid Torque Bar Transmission: All rotational forces are transmitted via heavy-duty steel torque bars rather than the walls of the actuating tube. This configuration safeguards the flexible neoprene air bladder from mechanical stress and significantly extends part life.
- Component-Level Serviceability: Field-serviceable design allows for quick friction shoe replacement without the need to entirely disassemble the driving and driven shafts, minimizing your operation's unscheduled downtime.
- Scalable Dual Configurations: For ultra-demanding power transmission requirements, all model sizes are available in dual-element configurations (e.g., Dual 66VC1600) to effectively double total torque and thermal handling capabilities.
PLEASE CONTACT US FOR GENUINE OEM PARTS YOU NEED.
Alpha Trading International is a global distributor to many countries including:
Chile, Brazil, Columbia, Suriname and Peru.
Danfoss Airflex VC units are built for severe clutching or braking applications in which large inertia loads and sustained slippage would normally result
in loss of torque and reduced operating life.
Torque: up to 1,706,629 Nm
Max. speed: 1,800 rpm
Typical applications: grinding mills.
Danfoss Airfex Clutches and Brakes
When it comes to powering heavy machinery in demanding environments like mining and locomotives, reliability is key. That’s where Danfoss Airflex clutches and brakes come into play. These components are engineered for performance, ensuring that equipment runs smoothly under the toughest conditions. But what really sets them apart? Let’s dive deeper into the world of genuine Danfoss OEM parts and discover how they can enhance efficiency and safety in your operations. Whether you’re looking to replace old components or upgrade your existing systems, understanding these high-quality products will help you make informed choices that propel your business forward.
Genuine Danfoss OEM parts
Genuine Danfoss OEM parts are synonymous with quality and reliability. Designed specifically for optimal performance, these components ensure your machinery operates at its best.
Using genuine parts means you’re investing in longevity. They undergo rigorous testing to meet industry standards, guaranteeing durability even under extreme conditions. This is essential in sectors like mining and locomotives where equipment faces harsh environments daily.
Moreover, opting for OEM parts simplifies maintenance. With a precise fit and compatibility, installation becomes straightforward, reducing downtime significantly.
In addition to functionality, genuine Danfoss components come backed by the manufacturer’s support. You gain peace of mind knowing that expert assistance is just a call away if needed.
Choosing OEM means choosing excellence for your operations ensuring every piece of machinery performs efficiently when it matters most.
Danfoss Airflex Eaton Clutches and Brakes
Danfoss Airflex Eaton clutches and brakes are renowned for their reliability and performance in demanding environments. These components play a crucial role in various industries, including mining and locomotives.
Designed for durability, they withstand the harshest conditions. Their advanced engineering ensures smooth operation under heavy loads. This makes them a top choice for professionals seeking efficiency.
One standout feature is their versatility. They can be used in multiple applications, serving both industrial machinery and transportation systems effectively.
Additionally, these clutches and brakes contribute to safety by providing precise control over movement. Whether starting or stopping operations, they perform consistently well.
Using Danfoss Airflex Eaton products means investing in quality that enhances productivity while minimizing downtime. With such reliable components at your disposal, you can focus on what truly matters keeping your operations running smoothly.
Genuine Aftermarket OEM parts from Danfoss
When it comes to performance and reliability, genuine aftermarket OEM parts from Danfoss stand out. They are engineered specifically for your equipment, ensuring a perfect fit and optimal function.
Using these authentic components means less downtime and improved efficiency in operations. The manufacturing processes adhere to the highest quality standards, which is vital in demanding environments like mining or locomotives.
Furthermore, Alpha Trading International distributes genuine Danfoss parts which all come with extensive support. Whether you need assistance during installation or troubleshooting later on, their service team is ready to help.
Opting for Genuine aftermarket OEM parts over generic alternatives guarantees longevity. This investment pays off by reducing maintenance costs in the long run. With Danfoss parts, you’re choosing durability that withstands rigorous use without compromising standards.
